Paxton 477-901 Power Over Ethernet Wireless Bridge for Net2 Air
Out of stock
Overview
Paxton 477-309 Power over Ethernet Bridge for Net2 and Net2 Nano
Paxton 477-901 Power over Ethernet Bridge connecting a PC running the NET2 software with control units. This unit plugs into a standard RJ45 Network connection, power can be taken from a PSU or PoE, power over ethernet.
- Wireless bridge from Net2 to wireless control units
- Plugs into the existing LAN/WAN
- Multiple Ethernet bridges can be placed around a site
- Gives more flexibility on installing wireless control units
- Power over Ethernet (PoE)
| Specifications - Net2Air bridge - Ethernet, PoE, Plastic housing | ||||
| min | typ | max | units | |
| Electrical | ||||
| Operating voltage | 11 | 12 | 14 | V DC |
| Current consumption | 150 | mA | ||
| Carrier frequency | 2.4 | GHz | ||
| Ethernet network speed | 10 | 100 | Mbps | |
| DHCP support | Yes (static IP recommended) | |||
| Power over Ethernet | Yes | |||
| Power supply included | Yes | |||
| System Specification | ||||
| Max number of ACUs per system | 1000 | |||
| Communication range to Net2 nano ACU | 3 | 20 | m | |
| Max Ethernet bridges per system | 100 | |||
| Max recommended ACU's per bridge | 10 | |||
| Environment | ||||
| Operating temperature | -20 | 55 | °C | |
| Moisture resistance | None | |||
