Union-Chubb 3K75 5 Lever Mortice Sashlock 67mm Satin Chrome
Union-Chubb 3K75 5 Lever Sashlock
The Union C-Series 3K75 5 Lever Sashlock is a high-quality lock designed for use on external doors. It features a 5 lever mechanism that provides extra security against picking and drilling, making it suitable for use in high-risk areas.
The sashlock is made from durable materials, including a hardened steel case and a deadbolt that is resistant to hacksaw attacks. The lock is designed to be used with a handle set, and can be used on both left and right-handed doors.
The lock is supplied with two keys as standard, and is available in a range of sizes. It is also available in a range of finishes, including brass, and satin chrome, so you can choose the one that best suits your needs.
In addition, the Union 3K75 sashlock includes a roller latch bolt to prevent the door from being forced open from the frame side. The roller latch bolt also helps to prevent damage to the door and door frame caused by slamming.
Overall, the Union C-Series 3K75 5 Lever Sashlock is a reliable and secure lock that provides excellent protection for your property. It is easy to install and comes with all the necessary fixings, making it a popular choice for homeowners and businesses alike.
Mechanism: 5 Lever
Case size: 67 and 80mm
Follower: 8mm
Case finish: Gold
Forend finish: Brass and Satin chrome
Keys Supplied: 2
Keyed Alike: Yes email for details
Master Keyed: No
Differs: 750+
Features
Roller latchbolt means lock is suitable for fitting in doors both left and right hand hung, without modification
Operation
Deadbolt is locked or unlocked by key from either side. Roller latchbolt withdrawn by lever handle from either side
Please note - All Chubb branded products are moving over to the Yale or Union brands, therefore the item that you receive maybe branded as Yale or Union instead of Chubb.
Size
|
Case Depth (A)
|
Backset (B)
|
Case Height (C)
|
Centres (D)
|
Forend Length (E)
|
Forend Width (F)
|
|
| 67mm |
67
|
40
|
108
|
56
|
152
|
25
|
| 80mm |
80
|
53
|
108
|
56
|
152
|
25
|
